Model Selection | ||||||||
Product Series | Test Mode | Pressure Type | Test pressure range | Voltage regulation method | Valve island type | Number of channels | Sensor accuracy | Other |
P | P: Direct pressure |
P: Positive pressure M: Positive and negative pressure N: Negative pressure
| L:0～100 KPa M:5～350 KPa H:10～700 KPa V:-5～-80 KPa A: Other ranges | M: Mechanical voltage regulation E: Electric voltage regulation |
02: Standard | C1: Single channel C2: Dual channel C4: Quad channel | L:±0.05%FS | A: Other ranges |
PA | P | P | M | M | 02 | C1 | L |
|
P series direct pressure instrument performance parameters | |||||
Test pressure range | L | M | H | V | |
Pressure regulation (mechanical pressure regulation) | 5～100KPa | 5～400KPa | 10～800KPa | -5～-80KPa | |
Pressure regulation (electronic pressure regulation) | 5～100KPa | 5～500KPa | 10～900KPa | -5～-80KPa | |
Pressure regulation accuracy | Mechanical voltage regulation: ±0.05%FS Electronic voltage regulation: ±0.5%FS | ||||
Sensor accuracy | ±0.05%FS | ||||
Effective resolution | Better than 1Pa | Better than 2Pa | Better than 3Pa | Better than 1Pa | |
Language | Chinese, English | ||||
Number of program channels | 32 | ||||
Test mode | Direct pressure type | ||||
Display | 7-inch touch screen | ||||
Store data | 1 million groups | ||||
USB | Copy data/barcode | ||||
RS485 | Modbus RTU | ||||
RS232 | Printer interface | ||||
Network port | Modbus TCP/IP | ||||
I/O interface | 4 I/6 O | ||||
